Plascraft supplies a range of high energy Metal oxide varistors from 7 to 20mm and produces a range of custom varistors from 32mm to 40mm Square in single or multiple configurations for energy ratings up to 75 KA . A range of high performance surge filters is produced with current ratings up to 25 amps. Surge arrestors up to 25Ka are available . Assembly of Varistor discs with Tabs or Leads and Epoxy resin coating is undertaken to Customers requirements. RC-Networks for Spark suppression on relays and similar applications |
Metal Oxide Varistor Application Notes
Applications Surge Protection in Consumer Electronics. Industrial Electronics. Telephone and Telecommunication systems. Automotive Equipment. Measuring and Controlling systems. Electronic home Appliances |
Section 3: Surge Protection Devices |
Type |
Varistors |
|
Metal Oxide Varistors : 7 mm 1.2 KA |
|
Metal Oxide Varistors : 10mm, 3.5 KA |
|
Metal Oxide Varistors : 14mm 6.5KA |
|
Metal Oxide Varistors : 20mm 10 KA |
|
Metal Oxide Varistors : 32mm :25KA For Energy Meters |
|
Metal Oxide Varistors : 40mm Square : 40KA, For DB Board Surge Protectors |
|
Metal Oxide Varistor With Integrated Thermal Disconnects For PCB Mounting |
|
Surge Arresters |
|
Surge Arresters, Single Phase 2 Wire |
|
Surge Arresters, Single Phase 2 Wire Class II Thermally Protected |
|
|
|
Surge Arresters, Single Phase 3 Wire Class II Thermally Protected |
|
Surge Arresters, 3 Phase |
|
Surge Arrester , 3 Phase Class II Thermally protected |
|
L.E.D. Lighting Surge Protectors for LED Driver Circuits in LED Lighting Fixtures |
|
L.E.D Lighting surge Protectors for LED Driver Circuits Class II Thermally protected |
|
Surge Filters |
|
L.E.D. Lighting Surge Filters for LED Driver circuits and Quality of supply problems In LED Lighting Systems . |
|
Surge Filters . Metal Box Types For enhanced protection of Telecom equipment , Computers , Industrial Equipment, against induced spikes Class 2 |
|
Surge Filters . Plastic Housing Single PI Types For protection of Telecom equipment , Computers , Industrial Equipment, against induced spikes Class 2 |
|
Surge Filters . Plastic Housing Double PI Types For protection of Telecom equipment , Computers , Industrial Equipment, against induced spikes Class 2 |
|
Surge Filters Plug in Type |
|
Thermal Disconnects |
|
Thermal disconnects for MOV and load disconnection due to MOV or protection device failure |
